Stainless steel seamless tube Heat exchanger tube Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheate ASTM A213/A213M TP304,TP304L TP304H

Stainless steel seamless tube Heat exchanger tube Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheate ASTM A213/A213M TP304,TP304L TP304H

  • Stainless steel seamless tube Heat exchanger tube Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheate ASTM A213/A213M TP304,TP304L TP304H
  • Stainless steel seamless tube Heat exchanger tube Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheate ASTM A213/A213M TP304,TP304L TP304H
  • Stainless steel seamless tube Heat exchanger tube Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheate ASTM A213/A213M TP304,TP304L TP304H
  • Stainless steel seamless tube Heat exchanger tube Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheate ASTM A213/A213M TP304,TP304L TP304H
Stainless steel seamless tube Heat exchanger tube Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheate ASTM A213/A213M TP304,TP304L TP304H
รายละเอียดสินค้า:
สถานที่กำเนิด: จีน
ชื่อแบรนด์: YUHONG
ได้รับการรับรอง: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
หมายเลขรุ่น: TP304L ,TP304,TP304H
การชำระเงิน:
จำนวนสั่งซื้อขั้นต่ำ: 100กก
ราคา: สามารถต่อรองได้
รายละเอียดการบรรจุ: กล่องไม้ / กล่องเหล็ก / มัดพร้อมฝาพลาสติก
เวลาการส่งมอบ: 10 วัน
สามารถในการผลิต: ตามคำขอของลูกค้า
ติดต่อ
รายละเอียดสินค้า
ข้อมูลจำเพาะ: ASTM A213/A213M-2013 , ASME SA213/SA213M-2013 , A789 , SA789 วัสดุ: TP304/304L , TP316L , TP310S , TP316Ti , TP321/321H , TP347 , TP317
พิมพ์: หลอดตรง, U Bend Tube, Coil Tube พื้นผิว: อบอ่อน, ดองและอบอ่อน, ขัดเงา
บรรจุุภัณฑ์: เคสไม้อัด

Stainless steel seamless tube Heat exchanger tube Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheate ASTM A213/A213M TP304,TP304L TP304H



YUHONG GROUP we are one of the leading manufacturers of stainless steel seamless tube for heat exchanger .With the development more than 30 years ,we have much experience exporting to more than 85 countries .





Stainles steel seamless tube Specification:



The higher carbon content of SA213 TP304H increases its strength, so the tensile strength and yield strength of 304H is greater than 304L. SA213 TP304H has greater short term and long term creep strength than 304L at temperature up to 500 °C, and 304H is more resistant to sensitization than 304L. 304H is required in such applications.



A213 TP304H Chemical Element Composition Content (%)

Component C Si Mn P S Cr Ni
Minimum Value 0.04 - - - - 18 8
Maximum Value 0.1 1 2 0.045 0.03 20 11



A213 TP304H Mechanical Properties

Tensile Strength
σb
Mpa
Yield Point
σs
Mpa
Elongation or Extension Rate
δ
%
Hardness
HBW
                  ≥515           ≥205                                     ≥35           ≤192





A213 TP304H Size Range:

Production Outside Diameter Wall Thickness
Heat Exchanger Tube 6.00mm to 101.6mm 0.5mm to 8mm





Final Finishing

Solution Annealed & Pickled/Bright Annealed.





Type of Tubes:



U-bend & Straight.



Some of the quality tests carried out by us includes:

Corrosion Test Conducted only when specially requested by the client
Chemical Analysis Test done as per required quality standards
Destructive / Mechanical Testing Tensile | Hardness | Flattening | Flare | Flange
Reverse-bend and Re. flat tests Carried out in full compliance with relevant standards & ASTM A-450 and A-530 norms, which ensures trouble-free expansion, welding & use at customers end
Eddy Current Testing Done to detect homogeneities in subsurface by using Digital Flaw-mark Testing System
Hydrostatic Testing 100% Hydrostatic Testing carried out according to ASTM-A 450 norms for checking tube leakage, and biggest pressure we can support 20Mpa/7s .
Air Under Pressure Test To check any evidence of air leakage
Visual Inspection After passivation, every single length of tubes & pipes is subjected to thorough visual inspection by trained staff for detecting surface flaws & other imperfections


Supplementary Testing : Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing. The tests conducted under this include:

  • Eddy Current Testing
  • O.P Testing
  • Radiography Testing
  • Corrosion Testing
  • Micro Testing
  • Macro Testing
  • IGC Testing
  • Ultrasonic testing
  • Liquid Penetrate testing
  •
  •







Stainless steel seamless tube Heat exchanger tube Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheate ASTM A213/A213M TP304,TP304L TP304H 0
